Galvanized Iron Earthing Electrode
Hot-Dip Galvanized. Fast Fault Dissipation. Low Maintenance.
True Power Galvanized Iron Earthing Electrode is hot-dip galvanized for long-term corrosion protection. Available in models 40 MTPG, 50 MTPG and 80 MTPG, with outer pipe diameters of 48 mm, 58 mm and 88 mm (min) and lengths of 1, 2 and 3 metres. Inner strip: 25 × 3 mm. Moisture booster chemical bags are provided for low earth resistance. Brand: True Power.
| Model | Length (Mtr) | Terminal Size | Inner Strip | Outer Pipe Diameter (min) mm |
|---|---|---|---|---|
| 40 MTPG | 1, 2 & 3 | 40X6 | 25X3 | 48 |
| 50 MTPG | 1, 2 & 3 | 40X6 | 25X3 | 58 |
| 80 MTPG | 1, 2 & 3 | 50X6 | 25X3 | 88 |
- Hot dip galvanized for corrosion protection
- Designed for fast fault current dissipation
- Low maintenance on site
- Easy & Fast installation on site.
- The correct balance is where the soil pH is between 5.5 and 7.5, so every effort should be taken to check soil pH levels regularly
- Moisture booster chemical bags provided for low earth resistance
